Importing MongoDB Data Using SSIS 2012

I have embarked on a little quest to learn other database platforms (especially NoSQL) as more and more of our clients at Pragmatic Works have them in their enterprise, and want to be able to import data from them into their SQL Server data warehouses using SQL Server Integration Services (SSIS). While I found several articles that showed how to do so, these were outdated due to changes in the MongDB C# driver. After quite a bit of effort figuring out how to get this working, I thought I’d pass along my hard fought knowledge.

First, I assume you are familiar with MongoDB (http://www.mongodb.org/) and SQL Server (https://www.microsoft.com/en-us/sqlserver/default.aspx). In my examples I am using SSIS 2012 and MongoDB 2.4.8, along with the C# driver version 1.7 for MongoDB available at http://docs.mongodb.org/ecosystem/drivers/csharp/ .

First, download and install the C# driver. This next step is important, as there was a change that occurred with version 1.5 of the driver: the DLLs are no longer installed in the GAC (Global Assembly Cache) automatically. They must be there, however, for SSIS to be able to use them.

By default, my drivers were installed to C:\Program Files (x86)\MongoDB\CSharpDriver 1.7. You’ll want to open a CMD window in Administrator mode, and navigate to this folder. Next you’ll need GACUTIL, on my computer I found the most recent version at:

C:\Program Files (x86)\Microsoft SDKs\Windows\v8.1A\bin\NETFX 4.5.1 Tools\x64\

A simple trick to find yours: Since you are already in the CMD window, just move to the C:\Program Files (x86) folder, and do a “dir /s gacutil.exe”. It will list all occurrences of the program, just use the one with the most recent date. Register the dlls by entering these commands:

“C:\Program Files (x86)\Microsoft SDKs\Windows\v8.1A\bin\NETFX 4.5.1 Tools\x64\gacutil” /i MongDB.Bson.dll

“C:\Program Files (x86)\Microsoft SDKs\Windows\v8.1A\bin\NETFX 4.5.1 Tools\x64\gacutil” /i MongDB.Driver.dll

Note the “ quote marks around the path are important for the CMD window to correctly separate the gacutil program from the parameters.

Once that is done, create a new SQL Server Integration Services project in SQL Server Data Tools (SSDT), what used to be called BIDS in SQL Server 2008R2 (and previous). Put a Data Flow Task on the Control Flow design surface. Then open the Data Flow Task for editing.

Next, drag and drop a Script Component transformation onto the Data Flow design surface. When prompted, change the component type to Source.


Now edit the script transform by double clicking on it. Move to the Inputs and Outputs page. For my test, I am using the dbo.DimCurrency collection I created using the technique I documented in the previous post, Exporting Data from SQL Server to CSV Files for Import to MongoDB Using PowerShell ( http://arcanecode.com/2014/01/13/exporting-data-from-sql-server-to-csv-files-for-import-to-mongodb-using-powershell/ )

I renamed the output from “output” to “MongoDB_DimCurrency”. I then added four columns, CurrencyName, CurrencyAlternateKey, CurrencyKey, and ID.


Make sure to set CurrencyName, CurrencyAlternateKey, and ID to “Unicode string [DT_WSTR]” Data Type. Then change CurrencyKey to “four byte signed integer [DT_I4]”.

Now return to the Script page and click Edit Script. In the Solution Explorer pane, expand References, right click and pick Add Reference. Go to Browse, and navigate to the folder where the MongoDB C# drivers are installed. On my system it was in C:\Program Files (x86)\MongoDB\CSharpDriver 1.7\. Add both MongoDB.Driver.dll and MongoDB.Bson.dll.


Click OK when done, your Solution Explorer should now look something like:


Now in the script, expand the Namespaces region and add these lines:

using MongoDB.Bson;
using MongoDB.Driver;
using MongoDB.Bson.Serialization;

Now scroll down to the CreateNewOutputRows() procedure. Here is a sample of the code I used:

public override void CreateNewOutputRows()
{
  string connectionString = "mongodb://localhost";
  string databaseName = "AdventureWorksDW2014";

  var client = new MongoClient(connectionString);
  var server = client.GetServer();
  var database = server.GetDatabase(databaseName);
  string CurrencyKey = "";

  foreach (BsonDocument document in database.GetCollection<BsonDocument>("dbo.DimCurrency").FindAll())
  {
    MongoDBDimCurrencyBuffer.AddRow();
    MongoDBDimCurrencyBuffer.CurrencyName = document["CurrencyName"] == null ? "" : document["CurrencyName"].ToString();
    MongoDBDimCurrencyBuffer.CurrencyAlternateKey = document["CurrencyAlternateKey"] == null ? "" : document["CurrencyAlternateKey"].ToString();
    CurrencyKey = document["CurrencyKey"] == null ? "" : document["CurrencyKey"].ToString();

    MongoDBDimCurrencyBuffer.CurrencyKey = Convert.ToInt32(CurrencyKey);
    MongoDBDimCurrencyBuffer.ID = document["_id"] == null ? "" : document["_id"].ToString();
  }

}

I start by defining a connection string to the MongoDB server, followed by the database name. I then create a MongoClient object. Note the MongoClient is the new way of connecting to the MongoDB server. In earlier versions of the C# driver, you used MongoServer objects.

I then cycle through each document in the collection “dbo.DimCurrency”, using the FindAll() method. For each item I use the AddRow() method to add a row to the buffer. In order to find the proper name for the buffer I went to the Solution Explorer and expanded the BufferWrapper.cs file. This is a class created by the script transform with the name of the output buffer.


For each column in my outputs, I map a column from the document. Note the use of the ternary operator ? : to strip out nulls and replace them with empty strings. String columns you can map directly from the document object to the output buffers columns.

The CurrencyKey column, being an integer, had to be converted from a string to an integer. To make it simple I created a string variable to hold the return value from the document, then used the Convert class to convert it to an INT 32.

Once you’ve done all the above, validate the code by building the code. If that all checks out save your work, close the code window, then close the Script Transformation Editor by clicking OK.

Now place a destination of some kind on the Data Flow. Since I have my company’s Task Factory tools I used a TF Terminator Destination, but you could also use a Row Count destination. On the precedence constraint between the two, right click and Enable Data Viewer. Execute the package, if all goes well you should see:


A few final notes. This test was done using a MongoDB document schema that was flat, i.e. it didn’t have any documents embedded in the documents I was testing with. (Hopefully I’ll be able to test that in the future, but it will be the subject of a future post.) Second, the key was the registering of the DLLs in the GAC. Until I did that, I couldn’t get the package to execute. Finally, by using the newer API for the MongoDB objects I’ve ensured compatibility for the future.

Exporting Data from SQL Server to CSV Files for Import to MongoDB Using PowerShell

I’ve been exploring other database systems, in order to determine how to import data from them using SQL Server Integration Services (SSIS). My first step though was to create some test data. I wanted something familiar, so I decided to export the Adventure Works Data Warehouse sample database and import into MongoDB. While I had many options I decided the simplest way was to first export the data to CSV files, then use the MongoDB utility mongimport. Naturally I turned to PowerShell to create an automated, reusable process.

First, if you need the Adventure Works DW database, you’ll find it at http://msftdbprodsamples.codeplex.com/. Second, I did my export from a special version of Adventure Works DW I created called AdventureWorksDW2014. This is optional, but if you want to have a version of Adventure Works DW updated with current dates, see my post at http://arcanecode.com/2013/12/08/updating-adventureworksdw2012-for-2014/. Third, I assume you are familiar with MongoDB, but if you want to learn more go to http://www.mongodb.org/.

Below is the PowerShell 3 script I created. The script is broken into four regions. The first, User Settings, contains the variables that you the user might need to change to get the script to run. It has things like the name of the SQL Server database, the path to MongoDB, etc.

The second region, Common, establishes variables that are used by the remaining two regions. You shouldn’t need to change or alter these. The third region accesses SQL Server and exports each table in the selected database to a CSV format file.

The final region, “Generate MongoDB import commands”, creates a batch (.BAT) file which has all the commands needed to run mongoimport for each CSV file. I decided not to have the PowerShell script execute the .BAT file so it could be reviewed before it is run. There might be some tables you don’t want to import, etc.

It is also quite easy to adapt this script to just create CSV files from SQL Server without using the MongoDB piece. Simply remove the fourth and final region, then in the Common and User Settings regions remove any variables what begin with the prefix “mongo”.

As the comments do a good job of explaining what happens I’ll let you review the included documentation for step by step instructions.

#==================================================================================================
# SQLtoCSVtoMongoDb.ps1
# Robert C. Cain | @ArcaneCode |
http://arcanecode.com
#
# If you need a simple way to export data from SQL Server to MongoDb, here is one way to do it.
# The script starts by setting up some variables to the server environment (see the User Settings
# region)
#
# Next, it exports data from each table in the selected database to individual CSV files.
# Finally, it generates a batch file which executes mongoimport for each csv file to import
# into MongoDb.
#
# I broke this into four regions so if all that is desired is a simple export of data to CSVs,
# you can simply omit the final region along with any variables that begin with "mongo".
#
# While I could have gone ahead and run the batch file at the end, I chose not to in order to
# give you time to review the output prior to running the batch file.
#==================================================================================================

Clear-Host

#region User Settings

  # In this section, set the variables so they are appropriate for your project / environment

  # This is the spot where you want to store the generated CSVs.
  # Make sure it does NOT end in a \
  $csvPath = "C:\mongodb"

  # If you are running this on a computer other than the server, set the name of the server below
  $sqlServer = $env:COMPUTERNAME

  # If you have a named instance be sure replace "default" with the name of the instance
  $sqlInstance = "\default"

  # Enter the name of the database to export below
  $sqlDatabaseName = "AdventureWorksDW2014"

  # The settings below only apply to the MongoDB code generation
  # Assemble path to mongodb. This assumes utlities are stored in the default bin folder
  $mongoPath = "C:\mongodb"
  $mongoImport = "$mongoPath\bin\mongoimport"

  # Set the server name and port
  $mongoHost = "localhost"   # Leave blank to default to localhost
  $mongoPort = ""            # Leave blank to default to 27107

  # Set the user name and password, leave blank if it isn’t needed
  $mongoUser = ""
  $mongoPW = ""

  # Enter the name of the database to import to.
  $mongoDatabaseName = "AdventureWorksDW2014"

  # Upserts are REALLY slow, especially on large datasets. Setting this to $true will turn off
  # the upsert option. If set to true, you are responsible for either deleting all documents
  # in the collection before hand, or allowing the risk of duplicates.
  #
  # Setting to false will enable the upsert option for mongoimport, and attempt to determine the
  # keys and (if found) add them to the final mongoimport command.
  $mongoNoUpsert = $true

#endregion

#region Common ————————————————————————————

  # This section sets variables used by both regions below. There is no need to alter anything
  # in this region.

  # Import the SQLPS provider (if it’s not already loaded)
  if (-not (Get-PSProvider SqlServer))
    { Import-Module SQLPS -DisableNameChecking }

  # Assemble the full servername \ instance
  $sqlServerInstance = "$sqlServer\$sqlInstance"

  # Assemble the full path for the SQL Provider to get to the database
  $sqlDatabaseLocation = "SQLSERVER:\sql\$sqlServerInstance\databases\$sqlDatabaseName"

  # Now tack on the Tables ‘folder’ to the SQL Provider path, the move there
  $sqlTablesLocation = $sqlDatabaseLocation + "\Tables"
  Set-Location $sqlTablesLocation

  # Get a list of tables in this database
  $sqlTables = Get-ChildItem

#endregion

#region Export SQL Data —————————————————————————
  # In this section we will export data from each table in the database to a CSV file.
  # WARNING: If the CSV file exists, it will be overwritten.

  # These are just used to display informational messages during processing
  $sqlTableIterator = 0
  $sqlTableCount = $sqlTables.Count

  # Iterate over each table in the database
  foreach($sqlTable in $sqlTables)
  {
    $sqlTableName = $sqlTable.Schema + "." + $sqlTable.Name

    # I’ll grant you the next little bit of formatting for the progress messages is a bit
    # OCD on my part, but I like my output formatted and easy to read.
    $sqlTableIterator++
    $padCount = " " * (1 + $sqlTableCount.ToString().Length – $sqlTableIterator.ToString().Length)
    $sqlTableIteratorFormatted = $padCount + $sqlTableIterator

    if( $sqlTableName.Length -gt 50 )
      { $padTable = " " }
    else
      { $padTable = " " * (50 – $sqlTableName.Length) }

    Write-Host -ForegroundColor White -NoNewline "Processing Table $sqlTableIteratorFormatted of $sqlTableCount : $sqlTableName $padTable"

    # If the instance is "default", we have to exclude it when we use Invoke-SqlCmd
    if($sqlInstance.ToLower() -eq "\default")
      { $sqlSI = $sqlServer }
    else
      { $sqlSI = $sqlServerInstance }

    # Load an object with all the data in the table
    # Note if you have especially large tables you may need to modify this
    # section to break things into smaller chunks.
    $sqlCmd = "SELECT * FROM " + $sqlTableName
    $sqlData = Invoke-Sqlcmd -Query $sqlCmd `
                             -ServerInstance $sqlSI `
                             -SuppressProviderContextWarning `

    # Now write the data out.
    # Note utf8 encoding is important, as it is all mongoimport understands
    # Also need to omit the Type Info header PowerShell wants to write out
    Write-Host -ForegroundColor Yellow "    Writing to table $sqlTableName.csv"
    $sqlData | Export-Csv -NoTypeInformation -Encoding "utf8" -Path "$csvPath\$sqlTableName.csv"

  }

  # Just add a blank line after the processing ends
  Write-Host

#endregion

#region Generate MongoDB import commands ———————————————————-

  # In this region we will generage the commands to import our newly exported data
  # into an existing database in MongoDB. This is an example of our desired output (wrapped
  # onto multiple lines for readability, in the output it will be a single line):

  #  C:\mongodb>bin\mongoimport –host localhost -port 27107
  #                             –db AdventureWorksDW2014 –collection DimSalesReason
  #                             –username Me –password mySuperSecureP@ssW0rd!
  #                             –type csv –headerline –file DimSalesReason.csv
  #                             –upsert –upsertFields SalesReasonKey

  # Note several of these parameters are optional, and could use defaults, or be potentially
  # omitted from the final output, based on the choices at the very beginning of this script

  # Feel free to alter the $mongoCommand as needed for other circumstances

  # Final warning, the database must already exist in MongoDb in order to import the data. This
  # script will not generate the database for you.

  # Create the name for the batch file we will generate
  $mongoBat = $csvPath + "\Import_SQL_" + $sqlDatabaseName + "_to_MongoDb_" + $mongoDatabaseName + ".bat"

  # See if file exists, if so delete it
  if (Test-Path $mongoBat)
    { Remove-Item $mongoBat }

  # These are just used to display informational messages during processing
  $sqlTableIterator = 0
  $sqlTableCount = $sqlTables.Count

  # mongoimport allows us to do upserts, helping to eliminate duplicate rows on import.
  #
  # To make an upsert work there has to be a key column to match up on. Fortunately,
  # most tables in the SQL Server world have Primary Keys, so we can find out what
  # columns those are and add it to the command. Note if there is no PK in SQL Server,
  # no upsert will be attempted.
  #
  # Note though that upserts are REALLY slow, so the option to skip them is
  # built into the script and set at the top (mongoNoUpsert). The generated batch file
  # assumes that either a) you have deleted all data from the collection ahead of time,
  # or b) you are OK with the risk of duplicate data.

  # Iterate over each table in the database to build the mongoimport command
  foreach($sqlTable in $sqlTables)
  {
    $sqlTableName = $sqlTable.Schema + "." + $sqlTable.Name

    # A bit more OCD progress messages
    $sqlTableIterator++
    $padCount = " " * (1 + $sqlTableCount.ToString().Length – $sqlTableIterator.ToString().Length)
    $sqlTableIteratorFormatted = $padCount + $sqlTableIterator
    Write-Host -ForegroundColor Green "Building mongoimport command for table $sqlTableIteratorFormatted of $sqlTableCount : $sqlTableName"

    # Begin building the command
    $mongoCommand = "$mongoImport "

    if ($mongoHost.Length -ne 0)
      { $mongoCommand += "–host $mongoHost " }

    if ($mongoPort.Length -ne 0)
      { $mongoCommand += "–port $mongoPort " }

    $mongoCommand += "–db $mongoDatabaseName –collection $sqlTableName "

    if ($mongoUser.Length -ne 0)
      { $mongoCommand += " –username $mongoUser –password $mongoPW " }

    $mongoCommand += " –type csv –headerline –file $csvPath\$sqlTableName.csv "

    # Build the upsert clause, if the user has elected to use it.
    if ($mongoNoUpsert -eq $false)
    {
      $mongoPKs = ""
      foreach($sqlIndex in $sqlTable.Indexes)
      {
        if($sqlIndex.IndexKeyType -eq ‘DriPrimaryKey’)
        {
          foreach($sqlCol in $sqlIndex.IndexedColumns) #$sqlPKColumns)
          {
            if ($mongoPKs.Length -ne 0)
              { $mongoPKs += "," }
            # Note column names are returned with [ ] around them, and must be removed
            # Have to use -replace instead of .Replace() because $sqlCol is an column not a string
            $mongoPKs += ($sqlCol -replace "\[", "") -replace "\]", ""
          }

          $mongoCommand += " –upsert –upsertFields $mongoPKs"
        }
      }
    }

    # Append the command to the batch file
    $mongoCommand | Out-File -FilePath $mongoBat -Encoding utf8 -Append

  }

  # Just add a blank line after the processing ends
  Write-Host

#endregion



Updating AdventureWorksDW2012 for 2014

A while back I did a post that contained a script to update the AdventureWorksDW2012 database to have dates for the 2013 time period. This will allow folks to demo date related queries and be able to simply use things like GETDATE or NOW without having to do funky math tricks to take into account the pitifully out of date offering.

I’ve now updated the script for 2014, thought I’d pass along the updated version. Note some browsers don’t seem to render the script using the mono-spaced font I intend, but just ignore. Copy and paste into SQL Server Management Studio and it should work fine.

/*-----------------------------------------------------------------------------------------------*/
/* Updating AdventureWorks2012 for Today                                                         */
/*                                                                                               */
/* Robert C. Cain, http://arcanecode.com @ArcaneCode                                             */
/*                                                                                               */
/* Script Copyright (c) 2013 by Robert C. Cain                                                   */
/* AdventureWorks database Copyright (c) Microsoft.                                              */
/*                                                                                               */
/* This script will make a backup of the AdventureWorks2012DW database, then copy and restore it */
/* as AdventureWorksDW2014. It will then update it for current dates. 2008 now becomes 2014,     */
/* 2007 is now 2012, and so forth. This script is dependent on the AdventureWorks2012DW sample   */
/* database already being installed. It won't change AdventureWorksDW2012 in anyway.             */
/*                                                                                               */
/* Be warned, if AdventureWorksDW2014 exists, it will be deleted as part of this process.        */
/*                                                                                               */
/*-----------------------------------------------------------------------------------------------*/

PRINT 'Updating AdventureWorks2012 for Today - Starting'
GO

/*-----------------------------------------------------------------------------------------------*/
/* Step 1 - Make a copy of AdventureWorksDW2012 and restore as AdventureWorksDW2014              */
/*-----------------------------------------------------------------------------------------------*/
SET NOCOUNT ON

USE [master]

-- Step 1.1. Make a backup of AdventureWorksDW2012 ----------------------------------------------
PRINT 'Backing up AdventureWorksDW2012'
GO

BACKUP DATABASE [AdventureWorksDW2012]
    TO DISK = N'C:\Program Files\Microsoft SQL Server\MSSQL11.MSSQLSERVER\MSSQL\Backup\AdventureWorksDW2012.bak'
  WITH NOFORMAT,
       INIT,
       NAME = N'AdventureWorksDW2012-Full Database Backup',
       SKIP,
       NOREWIND,
       NOUNLOAD,
       STATS = 10
GO


-- Step 1.2. Delete the database AdventureWorksDW2014 if it exists ------------------------------
PRINT 'Deleting AdventureWorksDW2014, if it exists'
GO

IF (EXISTS (SELECT 1
              FROM master.dbo.sysdatabases
             WHERE name = 'AdventureWorksDW2014' )
   )
   EXEC msdb.dbo.sp_delete_database_backuphistory @database_name = N'AdventureWorksDW2014'
GO

IF (EXISTS (SELECT 1
              FROM master.dbo.sysdatabases
             WHERE name = 'AdventureWorksDW2014' )
   )
   DROP DATABASE [AdventureWorksDW2014]
GO

-- Step 1.3. Restore the database to a new copy -------------------------------------------------
PRINT 'Restoring AdventureWorksDW2012 to AdventureWorksDW2014'
GO

RESTORE DATABASE [AdventureWorksDW2014]
   FROM  DISK = N'C:\Program Files\Microsoft SQL Server\MSSQL11.MSSQLSERVER\MSSQL\Backup\AdventureWorksDW2012.bak'
   WITH  FILE = 1,
   MOVE N'AdventureWorksDW2012_Data'
     TO N'C:\Program Files\Microsoft SQL Server\MSSQL11.MSSQLSERVER\MSSQL\DATA\AdventureWorksDW2014_Data.mdf',
   MOVE N'AdventureWorksDW2012_Log'
     TO N'C:\Program Files\Microsoft SQL Server\MSSQL11.MSSQLSERVER\MSSQL\DATA\AdventureWorksDW2014_log.ldf',
        NOUNLOAD,  STATS = 5

GO

PRINT 'Done Creating AdventureWorksDW2014'
GO



/*-----------------------------------------------------------------------------------------------*/
/* Step 2. Create a helper function to convert dates to a YYYYMMDD format Date Id.               */
/*-----------------------------------------------------------------------------------------------*/

USE [AdventureWorksDW2014]
GO

IF EXISTS (SELECT [name] FROM [sys].[all_objects] WHERE [name] = 'DateToDateId')
  DROP FUNCTION [dbo].[DateToDateId];
GO

CREATE FUNCTION [dbo].[DateToDateId]
(
  @Date DATETIME
)
RETURNS INT
AS
BEGIN

  DECLARE @DateId  AS INT
  DECLARE @TodayId AS INT

  SET @TodayId = YEAR(GETDATE()) * 10000
               + MONTH(GETDATE()) * 100
               + DAY(GETDATE())

  -- If the date is missing, or a placeholder for a missing date, set to the Id for missing dates
  -- Else convert the date to an integer
  IF @Date IS NULL OR @Date = '1900-01-01' OR @Date = -1
    SET @DateId = -1
  ELSE
    BEGIN
      SET @DateId = YEAR(@Date) * 10000
                  + MONTH(@Date) * 100
                  + DAY(@Date)
    END

  -- If there's any data prior to 2000 it was incorrectly entered, mark it as missing
  IF @DateId BETWEEN 0 AND 19991231
    SET @DateId = -1

  -- Commented out for this project as future dates are OK
  -- If the date is in the future, don't allow it, change to missing
  -- IF @DateId > @TodayId
  --   SET @DateId = -1

  RETURN @DateId

END

GO




/*-----------------------------------------------------------------------------------------------*/
/* Step 3. Add new dates to the dbo.DimDate table.                                               */
/*-----------------------------------------------------------------------------------------------*/
PRINT 'Adding new dates to dbo.DimDate'
GO

SET NOCOUNT ON

-- Later we will be writing an INSERT INTO... SELECT FROM to insert the new record. I want to
-- join the day and month name memory variable tables, but need to have something to join to.
-- Since everything is calculated, we'll just create this little bogus table to have something
-- to select from.
DECLARE @BogusTable TABLE
  ( PK TINYINT)

INSERT INTO @BogusTable SELECT 1;


-- Create a table variable to hold the days of the week with their various language versions
DECLARE @DayNameTable TABLE
  ( [DayNumberOFWeek]      TINYINT
  , [EnglishDayNameOfWeek] NVARCHAR(10)
  , [SpanishDayNameOfWeek] NVARCHAR(10)
  , [FrenchDayNameOfWeek]  NVARCHAR(10)
  )

INSERT INTO @DayNameTable
SELECT DISTINCT
       [DayNumberOFWeek]
         , [EnglishDayNameOfWeek]
         , [SpanishDayNameOfWeek]
         , [FrenchDayNameOfWeek]
  FROM dbo.DimDate

-- Create a month table to hold the months and their language versions.
DECLARE @MonthNameTable TABLE
  ( [MonthNumberOfYear] TINYINT
  , [EnglishMonthName]  NVARCHAR(10)
  , [SpanishMonthName]  NVARCHAR(10)
  , [FrenchMonthName]   NVARCHAR(10)
  )

INSERT INTO @MonthNameTable
SELECT DISTINCT
       [MonthNumberOfYear]
     , [EnglishMonthName]
     , [SpanishMonthName]
     , [FrenchMonthName]
  FROM dbo.DimDate

-- This is the start and end date ranges to use to populate the
-- dbo.DimDate dimension. Change if it's 2014 and you run across this script.
DECLARE @FromDate AS DATE = '2011-01-01'
DECLARE @ThruDate AS DATE = '2015-12-31'

-- CurrentDate will be incremented each time through the loop below.
DECLARE @CurrentDate AS DATE
SET @CurrentDate = @FromDate

-- FiscalDate will be set six months into the future from the CurrentDate
DECLARE @FiscalDate  AS DATE

-- Now we simply loop over every date between the From and Thru, inserting the
-- calculated values into DimDate.
WHILE @CurrentDate <= @ThruDate
BEGIN

  SET @FiscalDate = DATEADD(m, 6, @CurrentDate)

  INSERT INTO dbo.DimDate
  SELECT [dbo].[DateToDateId](@CurrentDate)
       , @CurrentDate
       , DATEPART(dw, @CurrentDate) AS DayNumberOFWeek
       , d.EnglishDayNameOfWeek
       , d.SpanishDayNameOfWeek
       , d.FrenchDayNameOfWeek
       , DAY(@CurrentDate) AS DayNumberOfMonth
       , DATEPART(dy, @CurrentDate) AS DayNumberOfYear
       , DATEPART(wk, @CurrentDate) AS WeekNumberOfYear
       , m.EnglishMonthName
       , m.SpanishMonthName
       , m.FrenchMonthName
       , MONTH(@CurrentDate) AS MonthNumberOfYear
       , DATEPART(q, @CurrentDate) AS CalendarQuarter
       , YEAR(@CurrentDate) AS CalendarYear
       , IIF(MONTH(@CurrentDate) < 7, 1, 2) AS CalendarSemester
       , DATEPART(q, @FiscalDate) AS FiscalQuarter
       , YEAR(@FiscalDate) AS FiscalYear
       , IIF(MONTH(@FiscalDate) < 7, 1, 2) AS FiscalSemester
    FROM @BogusTable
    JOIN @DayNameTable d
      ON DATEPART(dw, @CurrentDate) = d.[DayNumberOFWeek]
    JOIN @MonthNameTable m
      ON MONTH(@CurrentDate) = m.MonthNumberOfYear

  SET @CurrentDate = DATEADD(d, 1, @CurrentDate)
END
GO

-- If you want to verify you can uncomment this line.
-- SELECT * FROM dbo.DimDate WHERE DateKey > 20110000

PRINT 'Done adding new dates to dbo.DimDate'
GO





/*-----------------------------------------------------------------------------------------------*/
/* Step 4. Update the Fact Tables with the new dates.                                            */
/*-----------------------------------------------------------------------------------------------*/


PRINT 'Update Fact Tables'
GO

SET NOCOUNT ON

-- To move forward five years, we simply add 50,000 to the date key

-- 4.1 FactFinance ------------------------------------------------------------------------------
PRINT '  FactFinance'
GO

UPDATE [dbo].[FactFinance]
   SET [DateKey] = [DateKey] + 60000;


-- 4.2 FactInternetSales ------------------------------------------------------------------------
PRINT '  FactInternetSales'
GO

-- There are a few rows where the due date is on leap year. Update these to back off a day
-- so the date add works OK
UPDATE [dbo].[FactInternetSales]
   SET [OrderDateKey] = 20080228
     , [OrderDate] = '2008-02-28'
 WHERE [OrderDateKey] = 20080229

UPDATE [dbo].[FactInternetSales]
   SET [DueDateKey] = 20080228
     , [DueDate] = '2008-02-28'
 WHERE [DueDateKey] = 20080229

UPDATE [dbo].[FactInternetSales]
   SET [ShipDateKey] = 20080228
     , [ShipDate] = '2008-02-28'
 WHERE [ShipDateKey] = 20080229

-- Now update the rest of the days.
UPDATE [dbo].[FactInternetSales]
   SET [OrderDateKey] = [OrderDateKey] + 60000
     , [DueDateKey] = [DueDateKey] + 60000
     , [ShipDateKey] = [ShipDateKey] + 60000
     , [OrderDate] = DATEADD(yy, 6, [OrderDate])
     , [DueDate] = DATEADD(yy, 6, [DueDate])
     , [ShipDate] = DATEADD(yy, 6, [ShipDate])


-- 4.3 FactResellerSales ------------------------------------------------------------------------
PRINT '  FactResellerSales'
GO

-- As with Internet Sales, there are rows where the due date is on leap year.
-- Update these to back off a day so the date add works OK
UPDATE [dbo].[FactResellerSales]
   SET [OrderDateKey] = 20080228
     , [OrderDate] = '2008-02-28'
 WHERE [OrderDateKey] = 20080229

UPDATE [dbo].[FactResellerSales]
   SET [DueDateKey] = 20080228
     , [DueDate] = '2008-02-28'
 WHERE [DueDateKey] = 20080229

UPDATE [dbo].[FactResellerSales]
   SET [ShipDateKey] = 20080228
     , [ShipDate] = '2008-02-28'
 WHERE [ShipDateKey] = 20080229

-- Now update the table
UPDATE [dbo].[FactResellerSales]
   SET [OrderDateKey] = [OrderDateKey] + 60000
     , [DueDateKey] = [DueDateKey] + 60000
     , [ShipDateKey] = [ShipDateKey] + 60000
     , [OrderDate] = DATEADD(yy, 6, [OrderDate])
     , [DueDate] = DATEADD(yy, 6, [DueDate])
     , [ShipDate] = DATEADD(yy, 6, [ShipDate])

-- 4.4 FactSalesQuota ---------------------------------------------------------------------------
PRINT '  FactSalesQuota'
GO

UPDATE [dbo].[FactSalesQuota]
   SET [DateKey] = [DateKey] + 60000

-- 4.5 FactSurveyResponse -----------------------------------------------------------------------
PRINT '  FactSurveyResponse'
GO

UPDATE [dbo].[FactSurveyResponse]
   SET [DateKey] = [DateKey] + 60000

-- 4.6 FactCallCenter ---------------------------------------------------------------------------
PRINT '  FactCallCenter'
GO

-- All the rows in call center have a 2010 date, just add 3 years to make these 2014
UPDATE [dbo].[FactCallCenter]
   SET [DateKey] = [DateKey] + 40000


-- 4.7 FactCurrencyRate -------------------------------------------------------------------------
PRINT '  FactCurrencyRate'
GO

-- Because the DateKey is part of the PK, we have to drop the key before we can update it
ALTER TABLE [dbo].[FactCurrencyRate] DROP CONSTRAINT [PK_FactCurrencyRate_CurrencyKey_DateKey]
GO

-- Shift the 2008 Leap Year days to 2012 Leap Year
UPDATE [dbo].[FactCurrencyRate]
   SET [DateKey] = 20120229
 WHERE [DateKey] = 20080229

-- Update everything except the leap year we fixed already
UPDATE [dbo].[FactCurrencyRate]
   SET [DateKey] = [DateKey] + 60000
 WHERE [DateKey] <> 20120229

-- Add the PK back
ALTER TABLE [dbo].[FactCurrencyRate]
  ADD CONSTRAINT [PK_FactCurrencyRate_CurrencyKey_DateKey] PRIMARY KEY CLUSTERED
      ( [CurrencyKey] ASC,
          [DateKey] ASC
      )
 WITH ( PAD_INDEX = OFF
      , STATISTICS_NORECOMPUTE = OFF
      , SORT_IN_TEMPDB = OFF
      , IGNORE_DUP_KEY = OFF
      , ONLINE = OFF
      , ALLOW_ROW_LOCKS = ON
      , ALLOW_PAGE_LOCKS = ON
      ) ON [PRIMARY]
GO


-- 4.8 FactProductInventory ---------------------------------------------------------------------
PRINT '  FactProductInventory'
GO

-- As with the previous step, the date is part of the primary key, so we need to drop it first.
ALTER TABLE [dbo].[FactProductInventory] DROP CONSTRAINT [PK_FactProductInventory]
GO

-- Shift the 2008 Leap Year days to 2012 Leap Year
UPDATE [dbo].[FactProductInventory]
   SET [DateKey] = 20120229
 WHERE [DateKey] = 20080229

-- Update everything except the leap year we fixed already
UPDATE [dbo].[FactProductInventory]
   SET [DateKey] = [DateKey] + 60000
 WHERE [DateKey] <> 20120229

-- Add the PK back
ALTER TABLE [dbo].[FactProductInventory]
  ADD CONSTRAINT [PK_FactProductInventory] PRIMARY KEY CLUSTERED
      (    [ProductKey] ASC
      , [DateKey] ASC
      )
 WITH ( PAD_INDEX = OFF
      , STATISTICS_NORECOMPUTE = OFF
      , SORT_IN_TEMPDB = OFF
      , IGNORE_DUP_KEY = OFF
      , ONLINE = OFF
      , ALLOW_ROW_LOCKS = ON
      , ALLOW_PAGE_LOCKS = ON
      ) ON [PRIMARY]
GO

PRINT 'Done updating the Fact tables'
GO



/*-----------------------------------------------------------------------------------------------*/
/* Step 5. Cleanup, remove the helper function we added earlier.                                 */
/*-----------------------------------------------------------------------------------------------*/
PRINT 'Removing Helper Function'
GO

IF EXISTS (SELECT 1 FROM [sys].[all_objects] WHERE [name] = 'DateToDateId')
  DROP FUNCTION [dbo].[DateToDateId];
GO

/*-----------------------------------------------------------------------------------------------*/
/* All done!                                                                                     */
/*-----------------------------------------------------------------------------------------------*/
PRINT 'Updating AdventureWorks2012 for Today - Completed'
GO

.csharpcode, .csharpcode pre
{
font-size: small;
color: black;
font-family: consolas, “Courier New”, courier, monospace;
background-color: #ffffff;
/*white-space: pre;*/
}
.csharpcode pre { margin: 0em; }
.csharpcode .rem { color: #008000; }
.csharpcode .kwrd { color: #0000ff; }
.csharpcode .str { color: #006080; }
.csharpcode .op { color: #0000c0; }
.csharpcode .preproc { color: #cc6633; }
.csharpcode .asp { background-color: #ffff00; }
.csharpcode .html { color: #800000; }
.csharpcode .attr { color: #ff0000; }
.csharpcode .alt
{
background-color: #f4f4f4;
width: 100%;
margin: 0em;
}
.csharpcode .lnum { color: #606060; }

SSAS Duplicate Attribute Error – Another Cause

I had  a real head banger this afternoon and I’m not talking about the heavy metal playlist I was jamming to in my iPod.

I had a table that, in addition to the surrogate key, business keys, etc had these columns:

Level1 Level2
Phineas and Ferb Phineas
Phineas and Ferb Ferb
Phineas and Ferb Perry

I had a dimension in SSAS where I had a Level1 -> Level2 Hierarchy built. When I tried to process the dimension, SSAS kept kicking out “duplicate attribute error” on Perry. I did the usual checking, yes my attribute relationships were OK, the Key property was built correctly, etc.

So then I moved to look at the data itself. I first did a SELECT * FROM CoolShow WHERE Level1 = ‘Phineas and Ferb’ and Level2 = ‘Perry’.

I got back 4 rows. Hmm. After some more head banging (Guns ‘n Roses, Paradise City) I wound up doing a SELECT * FROM CoolShow WHERE Level1 = ‘Phineas and Ferb’ and I get back 42 rows with Perry. Hmm, I say to myself, “self, that looks odd”. To which self replied “duh”.

Then self suggested I do a SELECT ‘*’ + Level2 + ‘*’ FROM CoolShow WHERE Level1 = ‘Phineas and Feb’

This yielded some interesting results, 4 rows read *Perry* the other rows read *Perry *   (Note the blank space between y and * .)

Well obviously I needed a RTRIM, which I dutifully added then reran the query. Only to get the *Perry * again in the output. At this point self said I was on my own and abandoned me to drown its sorrows in a pitcher of margaritas.

I took the output and copied it into an editor that would do hex mode. So what do I see but a 0D 0A in the space between the y and the *, causing me to scream “AH-HA” as Queen’s Bohemian Rhapsody hit its crescendo. I also scared the cat, but I only mention that because cute cat things are supposed to be popular on the internet and I figure it might help my SEO. For those who don’t speak HEX, 0D 0A is 13 and 10, which turn into a Carriage Return and Line Feed.

Now by this point most of you have probably given up on this handy tip, deciding a pitcher of margaritas sounded pretty good and left to find some. But if you are still hanging in, I modified the view with this code:

RTRIM(REPLACE(REPLACE([Level2], CHAR(13), ”), CHAR(10), ”) ) AS [Level2]

Returning to the cube I was able to process the dimension successfully and answer the question of “Where’s Perry?” (Answer: He’s at the bar trying to keep a drunken self from using his evil margaritainator invention.)

So the moral of the story, if you get duplicates error, and your dimension looks okey-dokey, check the data to see if you have some errant CR/LFs. Apparently SSAS doesn’t handle them very well.

Now if you’ll excuse me, I’m going to join self at the bar before self guzzles all the margaritas (self is such a drunken sot). AC/DC, take me away with some “Highway to Hell”!

Updating AdventureWorksDW2012 for Today

Like many of my fellow MVPs and Presenters, I use the Adventure Works sample data from Microsoft to do my presentations. Being a BI guy, I specifically use the AdventureWorksDW2012 version, the Data Warehouse of Adventure Works. I think you’d agree though it’s gotten a little long in the tooth. All of dates range from 2005 to 2008. This is especially irritating when demonstrating features reliant on the current date ( think GETDATE() or NOW() ).

Before you read further, let me stress again this is NOT for the typical AdventureWorks2012 database. This script is for the Data Warehouse version, AdventureWorksDW2012.

I scoured the search engines but couldn’t find anyone who had taken time to come up with a way to update the database. Finally fed up, I did it myself. Below is a script which will add five years to each date in AdventureWorksDW2012. 2008 becomes 2013, 2007 becomes 2012, and so on. The script, below, turned out to be pretty simple.

Before you begin though, a few prerequisites. First, you will need to have AdventureWorksDW2012 installed on your system. A friend and co-worker, Bradley Ball (@SQLBalls | blog ) pointed out one issue which I’ll pass along. He had some issues with the version of AdventureWorksDW2012 located at http://msftdbprodsamples.codeplex.com/releases/view/55330. When he just grabbed the mdf file and tried to create the database using the attach_rebuild_log option it came out corrupted. Instead he suggested the version stored at http://www.wrox.com/WileyCDA/Section/Wrox-Books-Using-the-SQL-Server-2012-RTM-Database-Examples-Download.id-811144.html?DW_1118479580.zip. (I don’t think Wrox will mind, as I and many of my co-workers have written books for them, nice folks.)

Next, please note this script was written with SQL Server 2012 in mind. It could easily be adapted for 2008R2 by tweaking a few paths. Speaking of which, I use the default paths for everything, you’ll need to alter if you used other paths.

Not wanting to mess with the original AdventureWorksDW2012, in Step 1 (these steps are numbered in the script below) I make a backup of the existing 2012 version. I then do a restore, renaming it to AdventureWorksDW2013. Be warned, if you have run this before and AdventureWorksDW2013 exists it will be deleted. This might be good if you want an easy way to reset your 2013 version, if not alter the script for your needs.

Later I will be inserting dates. I have a handy little routine that converts a traditional datetime data type to an integer, using the traditional YYYYMMDD common for data warehouse date keys. I probably could have done this using some version of FORMAT but I already had the routine written so I just grabbed and reused it. Note it also does some bounds checking, etc that really wasn’t needed here, but like I said I did a grab and reuse. So in Step 2 I create the function.

In step 3 I tackle the biggest task of inserting new rows into the date dimension. The DimDate table already had dates through the end of 2010, so I only had to generate 2011-2013. Inside a WHILE loop I iterate over each date individually, do the calculations to break out the various pieces of a date such as month number, quarter number, etc, and do an INSERT into the DimDate table. If you recall, the DimDate table in AdventureWorks has mult-language versions of the month and day names. I simply read the existing ones into table variables, then in the SELECT part of the INSERT INTO… SELECT statement do a join to these two table variables.

Of course to do that, I had to have a table to select from. None of my date data though existed in the table, each piece of data was generated from the CurrentDate variable. So I simply created a third table variable named BogusTable, and inserted a single row in it. This gave me something to join the month and day name tables to. I suppose I could have used CASE statements for each of the names, but this was more fun.

With the dates added to DimDate, it was time to move on to the Fact tables. In some cases it was very simple. For example, in Step 4.1 I just add 50,000 to the date key. Why 50,000? Simple date math. The dates are integers, 20080101 is really 20,080,101. To bring it up to 2013, I simply added 50,000, thus 20,013,101 or 20130101.

The two Sales fact tables had dates on leap year from 2008. To fix those I simply backed those up a day, shifting them to February 28th. I took a slightly different approach with the Currency Rate fact table, simply shifting the 2008 leap year to 2012 leap year, then omitting February 29th from the rest of the update. Also note that on this and the Product Inventory table, the Date Key was actually part of the Primary Key of the tables. Thus I had to first drop the Primary Key, make the changes to the dates, then recreate the Primary Key.

One last note on the Fact tables, all of the dates in the Call Center table were set to 2010. For those I merely added 30,000, shifting them from 2010 to 2013. (Don’t ask me why those have 2010 dates when the rest of the sample data is 2005-2008. I have not a clue.)

As a last and final step, Step 5, I drop the little helper function DateToDateId I created way back in Step 2. And that’s it! You now have a handy demo / practice database with dates that are actually current.

A big thanks to my co-workers at Pragmatic Works (@PragmaticWorks | http://pragmaticworks.com ) for helping me test this out and making sure it worked with their stuff.

Enjoy!



PS Most browsers don’t seem to render the code in a monospace font. Be assured when you paste into SSMS everything should line back up again, assuming of course you use a monospace font in SSMS.



/*-----------------------------------------------------------------------------------------------*/
/* Updating AdventureWorks2012 for Today */
/* */
/* Robert C. Cain, http://arcanecode.com @ArcaneCode */
/* */
/* Script Copyright (c) 2013 by Robert C. Cain */
/* AdventureWorks database Copyright (c) Microsoft. */
/* */
/* This script will make a backup of the AdventureWorks2012DW database, then copy and restore it */
/* as AdventureWorksDW2013. It will then update it for current dates. 2008 now becomes 2013, */
/* 2007 is now 2012, and so forth. This script is dependent on the AdventureWorks2012DW sample */
/* database already being installed. It won't change AdventureWorksDW2012 in anyway. */
/* */
/* Be warned, if AdventureWorksDW2013 exists, it will be deleted as part of this process. */
/* */
/*-----------------------------------------------------------------------------------------------*/

PRINT 'Updating AdventureWorks2012 for Today - Starting'
GO

/*-----------------------------------------------------------------------------------------------*/
/* Step 1 - Make a copy of AdventureWorksDW2012 and restore as AdventureWorksDW2013 */
/*-----------------------------------------------------------------------------------------------*/
SET NOCOUNT ON

USE [master]

-- Step 1.1. Make a backup of AdventureWorksDW2012 ----------------------------------------------
PRINT 'Backing up AdventureWorksDW2012'
GO

BACKUP DATABASE [AdventureWorksDW2012]
TO DISK = N'C:\Program Files\Microsoft SQL Server\MSSQL11.MSSQLSERVER\MSSQL\Backup\AdventureWorksDW2012.bak'
WITH NOFORMAT,
INIT,
NAME = N'AdventureWorksDW2012-Full Database Backup',
SKIP,
NOREWIND,
NOUNLOAD,
STATS = 10
GO


-- Step 1.2. Delete the database AdventureWorksDW2013 if it exists ------------------------------
PRINT 'Deleting AdventureWorksDW2013, if it exists'
GO

IF (EXISTS (SELECT 1
FROM master.dbo.sysdatabases
WHERE name = 'AdventureWorksDW2013' )
)
EXEC msdb.dbo.sp_delete_database_backuphistory @database_name = N'AdventureWorksDW2013'
GO

IF (EXISTS (SELECT 1
FROM master.dbo.sysdatabases
WHERE name = 'AdventureWorksDW2013' )
)
DROP DATABASE [AdventureWorksDW2013]
GO

-- Step 1.3. Restore the database to a new copy -------------------------------------------------
PRINT 'Restoring AdventureWorksDW2012 to AdventureWorksDW2013'
GO

RESTORE DATABASE [AdventureWorksDW2013]
FROM DISK = N'C:\Program Files\Microsoft SQL Server\MSSQL11.MSSQLSERVER\MSSQL\Backup\AdventureWorksDW2012.bak'
WITH FILE = 1,
MOVE N'AdventureWorksDW2012_Data'
TO N'C:\Program Files\Microsoft SQL Server\MSSQL11.MSSQLSERVER\MSSQL\DATA\AdventureWorksDW2013_Data.mdf',
MOVE N'AdventureWorksDW2012_Log'
TO N'C:\Program Files\Microsoft SQL Server\MSSQL11.MSSQLSERVER\MSSQL\DATA\AdventureWorksDW2013_log.ldf',
NOUNLOAD, STATS = 5

GO

PRINT 'Done Creating AdventureWorksDW2013'
GO



/*-----------------------------------------------------------------------------------------------*/
/* Step 2. Create a helper function to convert dates to a YYYYMMDD format Date Id. */
/*-----------------------------------------------------------------------------------------------*/

USE [AdventureWorksDW2013]
GO

IF EXISTS (SELECT [name] FROM [sys].[all_objects] WHERE [name] = 'DateToDateId')
DROP FUNCTION [dbo].[DateToDateId];
GO

CREATE FUNCTION [dbo].[DateToDateId]
(
@Date DATETIME
)
RETURNS INT
AS
BEGIN

DECLARE @DateId AS INT
DECLARE @TodayId AS INT

SET @TodayId = YEAR(GETDATE()) * 10000
+ MONTH(GETDATE()) * 100
+ DAY(GETDATE())

-- If the date is missing, or a placeholder for a missing date, set to the Id for missing dates
-- Else convert the date to an integer
IF @Date IS NULL OR @Date = '1900-01-01' OR @Date = -1
SET @DateId = -1
ELSE
BEGIN
SET @DateId = YEAR(@Date) * 10000
+ MONTH(@Date) * 100
+ DAY(@Date)
END

-- If there's any data prior to 2000 it was incorrectly entered, mark it as missing
IF @DateId BETWEEN 0 AND 19991231
SET @DateId = -1

-- Commented out for this project as future dates are OK
-- If the date is in the future, don't allow it, change to missing
-- IF @DateId > @TodayId
-- SET @DateId = -1

RETURN @DateId

END

GO




/*-----------------------------------------------------------------------------------------------*/
/* Step 3. Add new dates to the dbo.DimDate table. */
/*-----------------------------------------------------------------------------------------------*/
PRINT 'Adding new dates to dbo.DimDate'
GO

SET NOCOUNT ON

-- Later we will be writing an INSERT INTO... SELECT FROM to insert the new record. I want to
-- join the day and month name memory variable tables, but need to have something to join to.
-- Since everything is calculated, we'll just create this little bogus table to have something
-- to select from.
DECLARE @BogusTable TABLE
( PK TINYINT)

INSERT INTO @BogusTable SELECT 1;


-- Create a table variable to hold the days of the week with their various language versions
DECLARE @DayNameTable TABLE
( [DayNumberOFWeek] TINYINT
, [EnglishDayNameOfWeek] NVARCHAR(10)
, [SpanishDayNameOfWeek] NVARCHAR(10)
, [FrenchDayNameOfWeek] NVARCHAR(10)
)

INSERT INTO @DayNameTable
SELECT DISTINCT
[DayNumberOFWeek]
, [EnglishDayNameOfWeek]
, [SpanishDayNameOfWeek]
, [FrenchDayNameOfWeek]
FROM dbo.DimDate

-- Create a month table to hold the months and their language versions.
DECLARE @MonthNameTable TABLE
( [MonthNumberOfYear] TINYINT
, [EnglishMonthName] NVARCHAR(10)
, [SpanishMonthName] NVARCHAR(10)
, [FrenchMonthName] NVARCHAR(10)
)

INSERT INTO @MonthNameTable
SELECT DISTINCT
[MonthNumberOfYear]
, [EnglishMonthName]
, [SpanishMonthName]
, [FrenchMonthName]
FROM dbo.DimDate

-- This is the start and end date ranges to use to populate the
-- dbo.DimDate dimension. Change if it's 2014 and you run across this script.
DECLARE @FromDate AS DATE = '2011-01-01'
DECLARE @ThruDate AS DATE = '2013-12-31'

-- CurrentDate will be incremented each time through the loop below.
DECLARE @CurrentDate AS DATE
SET @CurrentDate = @FromDate

-- FiscalDate will be set six months into the future from the CurrentDate
DECLARE @FiscalDate AS DATE

-- Now we simply loop over every date between the From and Thru, inserting the
-- calculated values into DimDate.
WHILE @CurrentDate <= @ThruDate
BEGIN

SET @FiscalDate = DATEADD(m, 6, @CurrentDate)

INSERT INTO dbo.DimDate
SELECT [dbo].[DateToDateId](@CurrentDate)
, @CurrentDate
, DATEPART(dw, @CurrentDate) AS DayNumberOFWeek
, d.EnglishDayNameOfWeek
, d.SpanishDayNameOfWeek
, d.FrenchDayNameOfWeek
, DAY(@CurrentDate) AS DayNumberOfMonth
, DATEPART(dy, @CurrentDate) AS DayNumberOfYear
, DATEPART(wk, @CurrentDate) AS WeekNumberOfYear
, m.EnglishMonthName
, m.SpanishMonthName
, m.FrenchMonthName
, MONTH(@CurrentDate) AS MonthNumberOfYear
, DATEPART(q, @CurrentDate) AS CalendarQuarter
, YEAR(@CurrentDate) AS CalendarYear
, IIF(MONTH(@CurrentDate) < 7, 1, 2) AS CalendarSemester
, DATEPART(q, @FiscalDate) AS FiscalQuarter
, YEAR(@FiscalDate) AS FiscalYear
, IIF(MONTH(@FiscalDate) < 7, 1, 2) AS FiscalSemester
FROM @BogusTable
JOIN @DayNameTable d
ON DATEPART(dw, @CurrentDate) = d.[DayNumberOFWeek]
JOIN @MonthNameTable m
ON MONTH(@CurrentDate) = m.MonthNumberOfYear

SET @CurrentDate = DATEADD(d, 1, @CurrentDate)
END
GO

-- If you want to verify you can uncomment this line.
-- SELECT * FROM dbo.DimDate WHERE DateKey > 20110000

PRINT 'Done adding new dates to dbo.DimDate'
GO





/*-----------------------------------------------------------------------------------------------*/
/* Step 4. Update the Fact Tables with the new dates. */
/*-----------------------------------------------------------------------------------------------*/


PRINT 'Update Fact Tables'
GO

SET NOCOUNT ON

-- To move forward five years, we simply add 50,000 to the date key

-- 4.1 FactFinance ------------------------------------------------------------------------------
PRINT ' FactFinance'
GO

UPDATE [dbo].[FactFinance]
SET [DateKey] = [DateKey] + 50000;


-- 4.2 FactInternetSales ------------------------------------------------------------------------
PRINT ' FactInternetSales'
GO

-- There are a few rows where the due date is on leap year. Update these to back off a day
-- so the date add works OK
UPDATE [dbo].[FactInternetSales]
SET [OrderDateKey] = 20080228
, [OrderDate] = '2008-02-28'
WHERE [OrderDateKey] = 20080229

UPDATE [dbo].[FactInternetSales]
SET [DueDateKey] = 20080228
, [DueDate] = '2008-02-28'
WHERE [DueDateKey] = 20080229

UPDATE [dbo].[FactInternetSales]
SET [ShipDateKey] = 20080228
, [ShipDate] = '2008-02-28'
WHERE [ShipDateKey] = 20080229

-- Now update the rest of the days.
UPDATE [dbo].[FactInternetSales]
SET [OrderDateKey] = [OrderDateKey] + 50000
, [DueDateKey] = [DueDateKey] + 50000
, [ShipDateKey] = [ShipDateKey] + 50000
, [OrderDate] = DATEADD(yy, 5, [OrderDate])
, [DueDate] = DATEADD(yy, 5, [DueDate])
, [ShipDate] = DATEADD(yy, 5, [ShipDate])


-- 4.3 FactResellerSales ------------------------------------------------------------------------
PRINT ' FactResellerSales'
GO

-- As with Internet Sales, there are rows where the due date is on leap year.
-- Update these to back off a day so the date add works OK
UPDATE [dbo].[FactResellerSales]
SET [OrderDateKey] = 20080228
, [OrderDate] = '2008-02-28'
WHERE [OrderDateKey] = 20080229

UPDATE [dbo].[FactResellerSales]
SET [DueDateKey] = 20080228
, [DueDate] = '2008-02-28'
WHERE [DueDateKey] = 20080229

UPDATE [dbo].[FactResellerSales]
SET [ShipDateKey] = 20080228
, [ShipDate] = '2008-02-28'
WHERE [ShipDateKey] = 20080229

-- Now update the table
UPDATE [dbo].[FactResellerSales]
SET [OrderDateKey] = [OrderDateKey] + 50000
, [DueDateKey] = [DueDateKey] + 50000
, [ShipDateKey] = [ShipDateKey] + 50000
, [OrderDate] = DATEADD(yy, 5, [OrderDate])
, [DueDate] = DATEADD(yy, 5, [DueDate])
, [ShipDate] = DATEADD(yy, 5, [ShipDate])

-- 4.4 FactSalesQuota ---------------------------------------------------------------------------
PRINT ' FactSalesQuota'
GO

UPDATE [dbo].[FactSalesQuota]
SET [DateKey] = [DateKey] + 50000

-- 4.5 FactSurveyResponse -----------------------------------------------------------------------
PRINT ' FactSurveyResponse'
GO

UPDATE [dbo].[FactSurveyResponse]
SET [DateKey] = [DateKey] + 50000

-- 4.6 FactCallCenter ---------------------------------------------------------------------------
PRINT ' FactCallCenter'
GO

-- All the rows in call center have a 2010 date, just add 3 years to make these 2013
UPDATE [dbo].[FactCallCenter]
SET [DateKey] = [DateKey] + 30000


-- 4.7 FactCurrencyRate -------------------------------------------------------------------------
PRINT ' FactCurrencyRate'
GO

-- Because the DateKey is part of the PK, we have to drop the key before we can update it
ALTER TABLE [dbo].[FactCurrencyRate] DROP CONSTRAINT [PK_FactCurrencyRate_CurrencyKey_DateKey]
GO

-- Shift the 2008 Leap Year days to 2012 Leap Year
UPDATE [dbo].[FactCurrencyRate]
SET [DateKey] = 20120229
WHERE [DateKey] = 20080229

-- Update everything except the leap year we fixed already
UPDATE [dbo].[FactCurrencyRate]
SET [DateKey] = [DateKey] + 50000
WHERE [DateKey] <> 20120229

-- Add the PK back
ALTER TABLE [dbo].[FactCurrencyRate]
ADD CONSTRAINT [PK_FactCurrencyRate_CurrencyKey_DateKey] PRIMARY KEY CLUSTERED
( [CurrencyKey] ASC,
[DateKey] ASC
)
WITH ( PAD_INDEX = OFF
, STATISTICS_NORECOMPUTE = OFF
, SORT_IN_TEMPDB = OFF
, IGNORE_DUP_KEY = OFF
, ONLINE = OFF
, ALLOW_ROW_LOCKS = ON
, ALLOW_PAGE_LOCKS = ON
) ON [PRIMARY]
GO


-- 4.8 FactProductInventory ---------------------------------------------------------------------
PRINT ' FactProductInventory'
GO

-- As with the previous step, the date is part of the primary key, so we need to drop it first.
ALTER TABLE [dbo].[FactProductInventory] DROP CONSTRAINT [PK_FactProductInventory]
GO

-- Shift the 2008 Leap Year days to 2012 Leap Year
UPDATE [dbo].[FactProductInventory]
SET [DateKey] = 20120229
WHERE [DateKey] = 20080229

-- Update everything except the leap year we fixed already
UPDATE [dbo].[FactProductInventory]
SET [DateKey] = [DateKey] + 50000
WHERE [DateKey] <> 20120229

-- Add the PK back
ALTER TABLE [dbo].[FactProductInventory]
ADD CONSTRAINT [PK_FactProductInventory] PRIMARY KEY CLUSTERED
( [ProductKey] ASC
, [DateKey] ASC
)
WITH ( PAD_INDEX = OFF
, STATISTICS_NORECOMPUTE = OFF
, SORT_IN_TEMPDB = OFF
, IGNORE_DUP_KEY = OFF
, ONLINE = OFF
, ALLOW_ROW_LOCKS = ON
, ALLOW_PAGE_LOCKS = ON
) ON [PRIMARY]
GO

PRINT 'Done updating the Fact tables'
GO



/*-----------------------------------------------------------------------------------------------*/
/* Step 5. Cleanup, remove the helper function we added earlier. */
/*-----------------------------------------------------------------------------------------------*/
PRINT 'Removing Helper Function'
GO

IF EXISTS (SELECT 1 FROM [sys].[all_objects] WHERE [name] = 'DateToDateId')
DROP FUNCTION [dbo].[DateToDateId];
GO

/*-----------------------------------------------------------------------------------------------*/
/* All done! */
/*-----------------------------------------------------------------------------------------------*/
PRINT 'Updating AdventureWorks2012 for Today - Completed'
GO

SSDT – Error SQL70001 This statement is not recognized in this context

One of the most common errors I get asked about when using SQL Server Data Tools (SSDT) Database Projects is the error “This statement is not recognized in this context”. This is actually a pretty simple error to fix.

Envision this scenario. You have a simple table:

CREATE TABLE [dbo].[Test]
( [Id] INT IDENTITY NOT NULL PRIMARY KEY
, [SomeData] NVARCHAR(20) NOT NULL
)

Great. So then you want to have a post deployment script which will populate it with some default value. Because we are following best practices we creating a post deployment script which then calls the script to populate the default data.

:r .\InsertSomeData.sql

Then we have the script InsertSomeData.sql itself:

INSERT INTO [dbo].[Test] ([SomeData])
VALUES (‘Arcane Code’)

After inserting the code, or doing a build, you get this ugly error pop up in the error window:


So what happened? Well, when you went to insert the script you had these options in the dialog:




If you aren’t careful, you could accidentally pick the “Script (Build)” option (highlighted in blue). This option attempts to compile and run the code as DDL (Data Definition Language, the T-SQL syntax which creates tables, indexes, etc.) syntax. Things like Insert statements though are considered DML (Data Manipulation Language) code, and aren’t eligible to be compiled as part of the project. This is what generates the “This statement is not recognized in this context” error. You are essentially putting DML code where only DDL is allowed.

But don’t despair, this is extremely simple to fix. In SSDT, simply bring up the Properties dialog for the SQL script (click in the SQL script, then View, Properties in the menu). Pick the Build Action property, and change it to None.


And that’s it, the error “SQL70001 This statement is not recognized in this context” should now vanish from your error list.

Creating a Data Warehouse Date Id in Task Factory Advanced Derived Column Transformation

The company I work for, Pragmatic Works, makes a great tool called Task Factory. It’s a set of transformations that plug into SQL Server Integration Services and provides a wealth of new controls you can use in your packages. One of these is the Advanced Derived Column Transformation. If you are familiar with the regular Derived Column transformation built into SSIS, you know that it can be painful to use if you have to create anything other than a very basic calculation. Every try typing something complex into that single row tiny little box? Egad.

The Task Factory Advanced Derived Column transform allows you to pop up a dialog and have true multi-line editing. In addition there are 180 addition functions to make your life easier. Which is actually the point of this whole post.

As a Business Intelligence developer, one of the things I have to do almost daily is convert a date data type to an integer. Most dates (at least in the US) are in Month / Day / Year format. Overseas the format is usually Day / Month / Year (which to me makes more sense). SQL Server Analysis Services loves integer based field, so a common practice is to store dates as an integer in YYYYMMDD format.

Converting a date to an integer using the derived column transform can be ugly. Here’s an example of a fairly common (although not the only) way to do it:


(DT_I4)((DT_WSTR,4)YEAR(MyDateColumn) + RIGHT("00" + (DT_WSTR,2)MONTH(MyDateColumn),2) + RIGHT("00" + (DT_WSTR,2)DAY(MyDateColumn),2))

Task Factory makes this much easier. There is a ToChar function which converts columns or values to characters. This function allows you to pass in a format to convert to. Wrap all that in a ToInteger function and away you go. Check this out:


ToInteger(ToChar(MyDateColumn, "yyyyMMdd"))

Much, much simpler. One thing, the case of the format is very important. It must be yyyyMMdd, otherwise it won’t work. If you want to extend this more, you can actually check for a null, and if it is null return a –1 (a common Id for a missing row) or another special integer to indicate a missing value, such as 19000101.


IIf(IsNull(MyDateColumn)
   , -1
   , ToInteger(ToChar(MyDateColumn, "yyyyMMdd"))
   )

Here we first check to see if the column is null, if so we return the missing value, else we return the date converted integer. And yes, you can do multi line code inside the Advanced Derived Column Transformation.

As you can see the Advanced Derived Column Transformation makes working with dates much, much easier than the standard derived column transformation. This is such a common need that, at the risk of sounding like an ad, I decided to blog about it so I can share this with all my clients in the future.

(Just to be clear, it’s not an ad, I was not asked to do this, nor did I receive any money for it. Mostly I did this post just so I could share the syntax when I start each project or training class.)

I’m Speaking! SQL Saturday Nashville and PowerShell Saturday Atlanta

Just wanted to let folks know I’ll be doing presentations at two upcoming events.

The first is SQL Saturday #145 in Nashville. That’s this weekend, October 13th. I’ll be giving my “Introduction to Data Warehousing / Business Intelligence” presentation. Here is the slide deck I’ll be using: introtodatawarehousing.pdf

My second presentation will be October 27 in Atlanta at PowerShell Saturday #003. Yep, the PowerShell guys are taking the Saturday concept and kicking off a series of PowerShell Saturdays. This is only the third, but I see many more coming in the future.

At PowerShell Saturday I’ll be presenting “Make SQL Server Pop with PowerShell”. I’ll cover both the SMO and SQL Provider during this session.

Looks like it’ll be a busy October, but I’d hurry as both events are filling up so don’t wait and get registered now!

devLink 2012–SSDT in VS2012

Today I’m presenting SQL Server Data Tools in Visual Studio 2012. While the bulk of the information can be found in the blog posts over the last few weeks, I wanted to upload the slide deck. You’ll find it here:

http://arcanecode.files.wordpress.com/2012/08/ssdtinvs2012devlink1.pdf

SQL Server Data Tools in Visual Studio 2012–Schema Comparison

A feature carried over, but improved upon, from Visual Studio Database Projects is the Schema Comparison tool. The tool allows you to compare one database to another, a database to your project (or vice versa). It will also allow you to do comparisons between dacpacs and projects or databases (or them to dacpacs).

Doing one is pretty simple. We’ll keep using the project we’ve been using in previous lessons. For today’s example I’ve done a safe refactor on the JobTitle column in the HumanResources.Employee table, renaming it to JobName. I have also added a table and view to the dbo schema. For your example simply rename something in your project. After you make the changes, don’t publish them! We need something different for this example.

To kick off the schema compare, go to the SQL menu, then pick Schema Compare, New Schema Comparison. The dialog will be mostly empty, we’ll start with the upper portion.

SNAGHTML5a136e5

As you see, on the left we hit the drop down and will pick Select Source.

SNAGHTML5a33178

Here you have three choices. The top is to pick a project as your source. The second will let you pick an existing database as a source. The final choice will allow you to pick a dacpac file. For this example, we’ll pick the database that we created from our AdvWorks project, one prior to the changes you just made.

On the right, hit the drop down and for the target pick your AdvWorks project. Now click the Compare button in the upper left. SSDT will do the comparison and populate a dialog with the results.


In the upper half you will see a list of all the changes found. If you click on a change, the Object Definition area in the lower half populates with the code that creates the objects, and highlights the differences. In this example you’ll see that our source system has the JobTitle column, whereas the project on the right has our change to JobName.

The check boxes allow you to select or deselect individual changes. For example, you could go to the upper half which is designated to delete the ArcaneCode table and view and uncheck them. Then when you apply the changes these would be left untouched.

If you have a lot of changes you wish to omit, you can buik apply the exclusion (and likewise the inclusion) of files. Right click on a grouping (here the groups are changes and deletes), in the popup menu you can choose to Include All or Exclude All.

To apply the changes, simply click the Update button.

SNAGHTML5b39106You can choose how to group the comparisons findings. In the schema comparisons toolbar, you can choose to group by Action (the default), by the Schemas, or by Type (types being tables, views, etc).







You could have a situation that could result in data loss, for example the deletion of a table. By default SSDT will block any changes that will result in data loss in the target. Your target, however, might be a test database in which you don’t care if you lose data. There may also be other options you wish to override.

To see the options for applying updates, click on the gear immediately to the left of the grouping toolbar button.

SNAGHTML5b8182f

Here you can see a vast list of options available to you, that will affect the way in which SSDT applies updates to the target. You can see the “Block on possible data loss” option under the mouse, and could uncheck it to force your changes. There’s a lot of options here, so scroll through the list to see what other options you might be interested in.

Between the dropdowns for source and target is a little double arrow symbol. Click it will swap the source and target. Do it now, so the database now becomes the target and the project becomes the source. Now run the Compare again.

SNAGHTML5bcadd9You should now see the button between the Update and Options buttons become enabled. This is the Generate Script button, and becomes active when the target is a database.



Click it an a new window will appear with all the T-SQL that will change the target database to make it in sync with the project.

Let me stress something. This is not the way you should apply changes to your databases! The publish feature is the proper way to do that, in it are options to generate incremental updates.

This option is more for times when you have a test database you want to quickly get in sync, but for whatever reasons don’t want to create a full publish profile.

The Schema Comparison tool is surprisingly useful. A true story, I was working on a project one time that had considerable changes to an existing database. It was a short term project, so not a lot of time. In theory the source database was supposed to be left unchanged. Note I say “in theory”.

Bright and early Monday morning the very new to the job DBA comes to us and says “Oh by the way we had some issues over the weekend so I had to apply a bunch of changes.” When we asked for his scripts he just shrugged and said “I didn’t keep any of that junk. The changes are in the database just go get ‘em.” And with that wandered away, presumably to provide more sunshine to the lives of other dev teams.

At one time this would have been a major set-back. Fortunately the Schema Comparison tool quickly brought our project up to date. We were able to see the database changes before we applied them to our project, and in a few cases exclude the automatic changes and instead make them manually in our project.

Play around with the Schema Comparison tool, you can run it without actually applying changes. Knowing how to use it will help you on that fateful day when a new dba spreads a little sunshine into your own life.

SQL Server Data Tools in Visual Studio 2012–Customizing the Table Designer Layout

With this post I want to show you a few of the nice shortcuts provided to you in Visual Studio SSDT for quickly customizing the layout of your designers. A few of the items only apply to the table designer, but many apply to other windows within Visual Studio, no matter what project type is being hosted.


Number 1 points to the pane swap button. Clicking it will simply swap the positions of the grid and T-SQL windows, like so:


The double bar pointed to by number 2 is the resizing handle. Click and drag to adjust the amount of space used by either pane.


Note the change of the cursor shape when it’s hovered over the double bars.

There are three buttons pointed to by number 3. The middle one is the default, and indicates you want to split the panes horizontally. If you click the left most of these 3, it will split the panes vertically.


Vertical mode is really nice when you have a super wide screen monitor. As you can see, the three buttons have now shifted to the bottom center of the screen, next to the mouse in the above image.

What if you are working on a really small screen, and don’t even have enough real estate to work comfortably with any size split? Well that’s where the right (or bottom if vertically split) button comes in. Click it to shift to tabbed mode. (Note, I suggest you shift back to the default horizontal split first, otherwise the tabs will be on the right instead of the bottom and not quite as easy to use).


The last button, number 4, is for the T-SQL pane. It’s also found in almost all code editor windows in Visual Studio. Using it you can split the code view so you can see two different sections of you code at the same time.


Great for working with especially large code bases. And this split should exist in any text editor, not just the designer. Whether it’s straight T-SQL, VB.Net, C++, F#, or C# it should work for you.

For a typical desktop user, you’ll probably set these once and forget. But for folks like me who travel a lot, these are a real blessing. When I’m at home, with my laptop hooked up to my 25inch wide screen monitor, I can quickly shift to split screen vertical mode to take advantage of all that width.

When I’m on the road though, working on my laptops small screen (12 inches), I can shift back to horizontal mode, or more often (for me) tabbed mode, for doing my work.

Experiment with different layouts, and find out what works best for you!

SQL Server Data Tools in Visual Studio 2012–Safe Refactoring

With Visual Studio Database Projects (VSDB), you entered into Safe Refactoring mode through the Schema View window. But in SSDT, the Schema View window no longer exists. So how the heck do you do it??

Well first off, let’s define safe refactoring for those who may not have been familiar with the feature in VSDB. It allowed you to right click on a column name, and pick rename. You could then enter a new name, and hit the preview button. Visual Studio would comb through your source code and find every occurrence of that column name for that table and show it to you. If you clicked OK, Visual Studio would then go through and make the change everywhere for you, ensuring you didn’t miss anything.

Before we can do a safe refactor, we need to have something to refactor, and to test with. For this demo, we’ll create a simple view to read the dbo.ArcaneCode table we created in the previous post. Since there is no folder in the dbo schema for views, we’ll first have to create it.

Still working with our AdvWorks sample, open the dbo folder. Right click on it, and pick Add, Folder. Name the folder Views. Let me interject that strictly speaking, this isn’t a requirement. We could have placed the new view source file we’re about to create anywhere. But keeping a file/folder structure consistent with this and other SSDT projects will make maintenance far easier.

OK, once the folder is there, right click on it, again pick add, only this time pick a new View. Name the view dbo.vwArcaneCode.

CREATE VIEW [dbo].[vwArcaneCode] AS
SELECT [BlogUrl], [BlogAuthor]
FROM dbo.ArcaneCode

And save it. Now return to the table designer for the new ArcaneCode table.

Let’s decide we don’t like the name BlogUrl, and we’d rather call it BlogSite. Well, first we could try putting our cursor into the T-SQL area, and just typing over BlogUrl with BlogSite. What happens?

SNAGHTMLbdd349

Well, as you can see above, the designer on the upper half changes, but the column name in Create Index did not update. Not nearly what we wanted.

Let’s start over. Restore the name in the T-SQL area back to BlogUrl. Now go into the grid at the top, and change it there.

SNAGHTMLc00ed2

Hey, that’s better! Once we tabbed out of the Name column (or clicked elsewhere) it changed the name in all the locations in the T-SQL area. Just what we wanted!

Or is it?

Remember, we also used this column in the vwArcaneCode. Go take a look at its code.


As you can see, it remained unchanged. Even worse, there’s now a big red squiggly under the BlogUrl name, indicating we have now created an error in our project. Sigh. OK, one more time.

Go back to the table designer, and reset the name back to BlogUrl. Now we’re finally ready to do this the right way.

Put your cursor somewhere in the column name in the T-SQL area, then right click on the column name. Note, this will not work if you try it in the grid area at the top!

From the menu, pick Refactor, Rename.


You’ll now see a dialog appear, giving you a place to enter a new name. Change the name to BlogSite, and make sure the Preview Changes is checked on, then click OK.

SNAGHTMLc89a4f

Once you do, a new window will appear. It will show you everywhere the change would be made.

SNAGHTMLca7716

Looking at the window,  the upper part shows you all the files and the line of code in the file for which a change would be made. If you click on a line, the new version of the code will appear in the lower window. Ahh, there’s the view, and you can see it is being shown with the new change that will be made.

Note that no change has occurred as of yet. You must click the Apply button for anything to actually change. You can also click Cancel to abandon the change.

If you need to know everywhere a column name is used, but don’t want to change it, there’s an easy way to do that too. When we right clicked on the column name and picked Refactor, well a few menu options down was another option called “Find All References”. Picking that will populate a window in your Visual Studio environment.


When you click on a line in the above window, your central display in Visual Studio changes to now show the file you clicked on in this window.

There you go, you can now not only safely refactor column names in Visual Studio 2012 SSDT, but you can also find all references to that column within your project.

SQL Server Data Tools in Visual Studio 2012–Table Designer–Other Objects


Above is the screen shot of where things were left at the end of the previous post. We had just added a new table and used the designer to create four columns, along with their data types. We also saw how we can edit the table in T-SQL and see updates in the designer’s grid above.

But what’s all that stuff to the right of the grid? It would seem to list the various objects that would be associated with a table. In this case there’s only one, the unnamed Primary Key. But through this are we can also add new objects.

Let’s add a simple index. Right click on the Indexes (0) area. from the menu pick Add New, then for this example we’ll pick a standard Index.




When you do, a new index name appears below the Indexes (0) area, with a default name.

SNAGHTMLa8b905

Since this is going to be for the BlogUrl, I’m going to change the name to IX_ArcaneCode_BlogUrl. You’ll see the Indexes collection area has updated to reflect the new name, and the number in parenthesis has been updated to (1), to reflect the number of Indexes.

In the T-SQL area at the bottom, you’ll see some new T-SQL setup and ready for you to update. Here, all you have to do is change the [Column] to be the actual field name you wish to use in the index. In this case, [BlogUrl].

SNAGHTMLaa70bf

Think of the new designer as a combination of easy to use UI with a code generator. Creating other objects works just like you’ve seen here. You right click, pick what you want to add, and Visual Studio SSDT inserts the code template read for you to update.

SQL Server Data Tools in Visual Studio 2012–Table Designer

One of most noticeable enhancements to the data tools (over the previous database projects) is the table designer. Using the AdvWorks project we started in previous posts, let’s add a new table. Since the dbo schema has few tables, let’s add it there.

Expand the  dbo schema, right click on the Tables folder, right click and pick Add, Table as you can see in this illustration.

SNAGHTML28a093

Next you’ll be asked to confirm the type of object you wish to add, and what you want to name it. Ensure the “Table” object type is selected (the red arrow points it out below). Then, give your new table a good name. If you use multiple schemas in your database (and you should) then get into the habit of always typing in the schema name before the table name, even if it’s the default schema. This will prevent you from putting tables into the wrong schema, then having to clean up the mess later.

SNAGHTML2ae15a

You are now presented with the spiffy new table designer. Using it is fairly straightforward, but has some nice abilities.


You can begin by simply going to the Name area, and typing in new column names. I’m going to start by changing the word Id to ArcaneId. Next, move to the Data Type box and hit the dropdown. You’ll be presented with a dizzying array of data types!


For now I’ll leave it as int, since this will be my primary key, but I’ll add other types momentarily. I’ll leave Allow Nulls off, as well as leaving the default empty. Now add a column by moving down to the next row in the grid, perhaps call it BlogUrl, nvarchar(256). Note that when you pick the nvarchar column type, you’ll have to type right inside the Data Type text area to change the length of the column. Finally add a DateUpdated column, Date data type, an set the default to GETDATE().

Note that as you’ve filled in your columns in the designer, the T-SQL in the box underneath is also updating. It’s a two way street, shift down to the T-SQL code on the bottom. Let’s add a fourth column, but put it under the BlogUrl but above the DateUpdated. Let’s name it BlogAuthor, nvarchar(256), NULL (we’ll allow nulls) and no default.

When you get to the end of the line and VS has confirmed this is valid T-SQL code, it will update the designer area on the top to reflect what you’ve done below.

There is one more thing we should do, something that’s quite common especially in data warehousing. We should have the primary key be an Identity type, that is a column whose value auto-increments with each inserted record. We can’t do that via the designer area at the top. While we could move down to the T-SQL area at the bottom and just type it in, there is a way to do it graphically.

In the designer, click on the row with the ArcaneId. Now go to the Properties window (generally over on the right, below the Solution Explorer if you still have the default VS seutp). About 2/3 the way down you’ll see a property called Identity Specification. Using the + button expand it, then change the Is Identity property to true.


Now your designer window should look something like:


But that’s just the start, for this isn’t just a table designer, but a designer for keys, constraints, indexes, and more! But that will wait for the next post in the series.

SQL Server Data Tools in Visual Studio 2012–Publish Database Profile

One of the new features in SSDT, and what I consider to be my favorite, is the Publish Database Profiles. With database projects you could set a multitude of settings, everything from ANSI NULLS to whether to drop and create the database with each build. The only issue was these settings applied to the entire project; you had to change them each time you wanted to deploy to a different server, or to change the rules (overwrite vs. incremental for example).

New with SSDT are Publish profiles. They allow you to establish a set of rules and save them for reuse. To start with, right click on the project name and pick Publish from the menu.


You’ll now see a blank publish page.

SNAGHTML360f9789

Let’s start by tweaking some database settings. Click the Advanced button on the lower right.

SNAGHTML36114075

Here you can get to all of the options you can use to fine tune your database deployment. The most common appear at the top, the less changed ones appear in the list below. In this image I’ve checked on the option to Always re-create the database. This option will wipe out the existing database and recreate it from scratch.

Use this particular option with caution, especially if you are doing it to a database you are sharing with your co-workers (or even worse, production!). When your rebuild the database you’ll also lose any data and have to reload. Sometimes this is a good option, especially in the early stages of development when you’ve made massive changes to the database, or perhaps have gone into the database and made a lot of changes outside the scope of SSDT.

There may be other options you need to change, based on your environment or DBA requirements. Once you’ve changed your options click OK to return to the previous screen.

Back on the Publish Database settings dialog I’ll set the target database connection, and the name I want to use for the database. I can also set the output script name if I wish.



SNAGHTML36153d0b

Next, I want to be able to save this profile so I can reuse it later. Check on the “Add profile to project” option in the lower left, then click the Save Profile As… button.

SNAGHTML36195ad8

I gave it a good name, and made sure to include the most important options such as RecreateDB to indicate a database recreate was one of the options.

As I write this however, there is a bug with SSDT. When you click the “Add Profile to project” button it immediately adds a profile with the original default name. Then when you click the Save button in the dialog above, it adds the profile again, totally ignoring the name you give it. Instead it uses the default name again, only this time with an _1.

I’ve been assured that this bug is already known and has been fixed, and will be released with the next update to SSDT in VS2012. So depending on when you read this, it may or may not be an issue. Regardless, the fix is very easy, just rename the new .publish.xml file to reflect what you wanted it to be.

Once saved come back and hit Publish. The database will now be deployed to the server and the profile will be added to the solution. Here it is, after I’ve renamed the publish profile.


Note that I’ve given it a naming convention that specifies the database name, the target server, and any critical options. Here I’ve added “Overwrite” to indicate what will happen when I run it.

To run it, just double click on it. First, Visual Studio will do a build of the SSDT project. If there are any errors the process will be halted and you’ll need to fix them. If not, you’ll be presented with the publish dialog, this time with everything filled out.

SNAGHTML98453db

All you have to do is click Publish and the database will be created/updated using the options you’d picked previously, to the server which you had previously indicated.

Now for the real fun. Repeat the above steps only this time do NOT check the overwrite database option. Now, (after renaming the new profile) you have two publish profiles to pick from.


Take this even further. In my current project I have 8 profiles. An incremental and overwrite option for my local computer, the development server, the user acceptance testing server, and the production server. (In my case it’s a one man project, I’m the developer and the DBA all in one.) No longer do I have to juggle the server name, or even worse do a publish but forget to change the server from production back to local.

By far I think this is my favorite feature in SSDT.

Follow

Get every new post delivered to your Inbox.

Join 93 other followers
